S500-3.0-MH1-P

Fabco Air S Series Slide

Basic Model Selection

“S” Series (short) – single bearing block design, short overall length. “L” Series (long) – double bearing block design, increased bearing support.
Determine load capacity required and select a slide with appropriate guide shaft diameters and bearing block design. Use the convenient sizing guide at the right to determine safe loading and shaft defl ections for various stroke lengths.

Features:

• Pre-lubricated: All cylinders are factory lubricated with special high endurance oil.
• Pre-Tested: The quality of each assembly is assured by testing each unit for leakage and binding resistance prior to shipment.
• Bearing Block: Clear anodized aluminum with precision machined mounting surfaces
